The patch cord is made of G657A2 LSZH fiber cable with low insertion loss and high return loss and up to at least 80% 3D test.
| Single mode | Multimode | |
| Insertion Loss | ≤0.2dB | ≤0.25dB |
| Return Loss | ≥50dB(PC), ≥60dB(APC) | |
| Interchangeability | ≤0.2dB | |
| Tensile strength | >70N | |
| Operating Temperature | -40°C to +85°C | -20°C to +70°C |
Premium Fiber Cable: We utilize G657A2 LSZH fiber cable to ensure the highest quality standards, boasting minimal insertion loss and exceptional return loss.
Thoroughly Tested: With a rigorous 3D test that achieves an impressive 80% success rate, our SC LC Patch Cord are engineered for dependability and consistent performance.
Superior Performance: Experience low insertion loss – as low as ≤0.2dB (APC) and ≤0.3dB (PC) for SM, and ≤0.25dB for MM. Achieve exceptional return loss, ≥50dB (PC) and ≥60dB (APC).
Wide Temperature Tolerance: Designed to excel across varying conditions, our SC LC Patch Cord operate effectively from SM temperatures of -40°C to +85°C, and MM temperatures of -20°C to +70°C.
