Product profile

The ST To LC Duplex Patch Cable by A&T is designed with meticulous attention to both physical durability and optical performance, ensuring a reliable and efficient connectivity solution for various applications.

All jumpers have been rigorously tested before leaving the factory to ensure that the end faces are spotless and that the insertion loss and return loss are in compliance with international telecommunication standards.

Product features

Flexible Sheath: The 2.0mm optical fiber sheath offers flexibility while safeguarding the delicate fibers from external stresses, enhancing the cable's durability.

Easy Identification: Clear and legible printing on the cable aids in quick identification and organization, streamlining setup and maintenance.

Customization Options: Tailor your ST To LC Duplex Patch Cable to specific requirements, such as length, color, and connector types, allowing seamless integration into your network infrastructure.

Low Insertion Loss: With an insertion loss of ≤0.25 dB, our ST To LC Duplex Patch Cable guarantees minimal signal attenuation, supporting efficient data transmission.

High quality Fiber

CCTC Ceramic Ferrule

Connectors can be grade B

Brand new spare parts

Specifications	SC,LC,FC,E2000	ST,MU	MTRJ
SM	MM	SM	MM	SM	MM
UPC	APC	UPC	UPC	UPC	UPC	UPC
Work Wavelength (nm)	1310,1490,1550	850,1300	1310, 1490,1550	850,1300	1310,1490,1550	850,1300
Insertion Loss(dB)	≤0.25	≤0.20	≤0.25	≤0.25	≤0.25	≤0.25	≤0.25
Return Loss(dB)	≥55	≥65	≥35	≥50	≥35	≥50	≥35
Repeatability(dB)	≤0.10
interchangeability(dB)	≤0.20
Plug Testing(time)	≥1000
Tensile Strength(N)	0.9mm(9N);2.0mm(70N);3.0mm(75N)
Durability(dB)	≤0.20
Operation Temperature(°C)	-40~+75
Storage Termperature(°C)	-40~+85
