SC Adjustable Fiber Optic Attenuator – 1–30 dB

The SC Adjustable Type Fiber Optic Attenuator is designed for high-performance optical power control in both testing and operational environments. With its SC connector, it ensures a stable connection, while the adjustable attenuation feature allows for fine-tuning of signal strength to optimize network performance. This attenuator is suitable for a variety of applications, from telecommunications and data centers to FTTH networks, providing the flexibility needed to adapt to varying optical power levels.

Feature Details

• Adjustable Attenuation: Easily adjustable from 0 dB to 30 dB, offering precise control to meet specific network requirements.
• SC Connector: The SC connector ensures a secure, low-loss connection and is widely used in telecom and data applications.
• High-Quality Performance: Low insertion loss and high return loss, ensuring minimal impact on network performance.
• Durability: Designed with high-quality materials to withstand frequent use and environmental stress, ensuring a long service life.
• Broad Compatibility: Ideal for various fiber optic systems, including FTTH, telecom, and data center networks.

Application Details

• Telecommunication Networks: Allows precise control over signal strength, ensuring consistent network performance and signal integrity.
• Test and Measurement Systems: Ideal for use in optical test setups where fine control over signal attenuation is required.
• Data Centers: Used to adjust optical power levels and optimize performance in high-density fiber optic networks.
• FTTH Networks: Helps maintain optimal optical signal strength at the end-user’s premises, ensuring reliable service.

Feature Details

• Adjustable Attenuation: Easily adjustable from 0 dB to 30 dB, offering precise control to meet specific network requirements.
• SC Connector: The SC connector ensures a secure, low-loss connection and is widely used in telecom and data applications.
• High-Quality Performance: Low insertion loss and high return loss, ensuring minimal impact on network performance.
• Durability: Designed with high-quality materials to withstand frequent use and environmental stress, ensuring a long service life.
• Broad Compatibility: Ideal for various fiber optic systems, including FTTH, telecom, and data center networks.

Product Specifications:

Fiber Connector	SC
Transfer Mode	Single mode
Connector Gender	Adjustable
Attenuation Range	1-30dB
Attenuation Accuracy	±0.5dB(1dB-10dB); ±1.0dB(11dB-25dB)
Available Wavelengths	1310nm,1550nm,1310&1550nm
Wavelength Dependence	＜0.3dB Change in insertion loss for 1310-1550nm
Return Loss	≥50dB(UPC); ≥60dB(APC)
Polarization Dependent Loss	≤0.2dB
Temperature Range	-40-80°C(≤0.2dB in insertion loss)
Humidity Range	+/-0.2dB Change in 10% to 90% relative Humidity Range
Vibration	≤0.1dB Change between 10Hz to 55Hz
Drop	+/-0.2dB after 8 drops from 1.8meters onto a hard surface
Maximum Optical Input Power	200mW

Application Details

• Telecommunication Networks: Allows precise control over signal strength, ensuring consistent network performance and signal integrity.
• Test and Measurement Systems: Ideal for use in optical test setups where fine control over signal attenuation is required.
• Data Centers: Used to adjust optical power levels and optimize performance in high-density fiber optic networks.
• FTTH Networks: Helps maintain optimal optical signal strength at the end-user’s premises, ensuring reliable service.
